MONOPOLE GSM DUAL BAND SMA m - P/N 8610010
TECHNOLÓGIA:
GSM / UMTS / LTE Antennas
ÚČEL:
M2M / TLC / IoT
Antenna Monopole GSM Dual Band On device mount, SMA mConnector
Frequencies
Max Power: 4 W (CW)
VSWR: GSM TX < 2:1 RX < 2:1
Connector: SMA m On Device Mount
Overall dimension: ø10 mm Height: 74 mm
Weight: 14 g
Frequencies
- GSM: 890-960
- DCS: 1710-1880 MHz
Max Power: 4 W (CW)
VSWR: GSM TX < 2:1 RX < 2:1
Connector: SMA m On Device Mount
Overall dimension: ø10 mm Height: 74 mm
Weight: 14 g
